Surge Protector(REP-SD24EX Series) for Signal System

lightning surge protector for signal transmission system

PRODUCTS DETAIL

Product Picture

REP-SD24EX Series

Features

●REP-SD24EX is made of corrosion resistant stainless steel and can be directly screwed onto a field device against surge in potentially explosive atmospheres.

●Small size, long lifetime, Ip67.

●High discharge capacity, low Up, fast response.

●The surge protector is ideally suited for installation in potentially explosive area, for example gas station, oil tank etc.

Datasheet

Type	REP-SD24EX
SPD port	Two ports
Nominal voltage(Un)	24V
Max. continuous operating voltage(Uc)	27V
Rated load current(IL)	0.5A
Nominal discharge current (8/20 μs)ln	5KA
Maximum discharge current(8/20)(Imax)	10KA
Voltage protection level (Up)	≤60V
Max. transfer rate	2Mbps
Insert loss	<0.1dB
Degree of protection	Ip67
Protection mode	Balance / Imbalance(Optional)
Grounding mode	Direct / Indirect(Optional)
Failure mechanism	The communication line is short circuit to ground or open circuit.
