PRODUCTS DETAIL
Product Picture
Datasheet
|
Model
|
REP-MP20T2-385-4S |
|
The SPD according to IEC/EN 61643-11 |
Type 2
|
|
Maximum continuous voltage Uc
|
150Vac
|
|
Impulse discharge current Iimp (10/350μs)(N-PE)
|
12.5kA
|
|
Nominal discharge current In (8/20μs)
|
20kA
|
|
Maximum discharge current Imax (8/20μs)
|
40kA
|
|
Voltage protection level(Up)@In
|
1.1kV
|
|
Response time(t.)
|
25ns
|
|
Short-circuit withstand capability Isccr
|
25kArms
|
|
Temporary overvoltage(TOV) UT
|
210V / 5sec.
|
|
Operating temperature range(Tu)
|
-40℃～80℃
|
|
Work/Fault indicator
|
Green: Normal ; Red: Failure
|
|
Remote alarm contact
|
NO/NC/C, Isolated Form C
|
|
Remote alarm contact capability Un/In
|
AC:250/0.5A DC:250V/0.1A;75V/0.5A
|
|
Remote alarm contact connecting wire
|
Max.1.5mm² or#16AWG
|
|
The minimum cross-sectional area of installation
|
1.5mm² solid/flexible
|
|
The maximum cross-sectional area of installation
|
25mm² solid/flexible
|
|
Installation
|
35mmDINrail,according to EN 60715
|
|
Shell material
|
Red thermoplastic material ,UL94 V-0
|
|
The installation location
|
Indoor
|
|
Degree of protection
|
IP20
|
|
Size
|
2 modules
|
|
Certification
|
TUV
|
|
Dimensions(mm)
|
Diagram
|
 |
 |
